B2B Wholesale Gantry-type Double-column Fift
Product Highlights:
- Explosion-proof valves installed in hydraulic circuit for safety. Sliders made of nano-material, wear-resistant and maintenance-free.
- Environment-friendly & low-noise design. 600mm extended arm provides extra 1200mm lifting height, maximizing workspace.
- Unique mechanical synchronization ensures stable and balanced arm movement.
- Base plate thickness: 20mm with arm thickness: 6mm/8mm. Hydraulic cylinder with double ear design.
- Sliding shoes on arms allow easy driving over ramps. 1.8m extended design on base and arms for more vehicle compatibility.
- Each lift has passed 115% dynamic load test and 150% static load test, ensuring equipment reliability.
- Full product liability insurance is included with every lift.
Technical Parameters:
| Model | BETA 45 | BETA 55 |
| Lifting Capacity | 4500 kg | 5500 kg |
| Lifting Time | 50 s | 50 s |
| Lowering Time | 50 s | 50 s |
| Motor Power | 3 kW | 3 kW |
| Max Lifting Height | 2050 mm | 2050 mm |
| Min Height | 115 mm | 115 mm |
| Overall Height | 3953mm/4180mm | 3953mm/4180mm |
| Overall Width | 3350mm | 3350mm |
| Net / Gross Weight | 930kg / 984kg | 1014kg / 1068kg |
| Package Size (Main) | 3988*1091*520mm | 3988*1174*520mm |
| Package Size (Accessory) | 820*350*637mm | 820*350*637mm |
