Custom Wholesale Modern Bottom-mounted Two Posts Lift
Product Highlights:
- The hydraulic circuit is equipped with explosion-proof valves for safety. Sliders are made of nano-material, wear-resistant and maintenance-free. Cylinder adopts Ø50mm piston rod with 3-year warranty.
- Environment-friendly, low-noise design. Column adopts 8-fold bending structure with built-in reinforcing ribs for maximum strength. Unique electronic cable equalization, multi-steel wire rope synchronization. 0.7m low-profile design with sliding shoes on arms, easy to drive over thresholds.
- Base plate thickness: 16mm / 20mm. Rubber pad tray included for durability. Equipped with chain tension protection device.
- Each lift has passed 115% dynamic load test and 150% static load test to ensure equipment reliability.
- Full product liability insurance is included with every lift.
Technical Parameters:
| Lifting Capacity | 3500 kg | 4500 kg |
| Lifting Time | 50 s | 50 s |
| Lowering Time | 50 s | 50 s |
| Motor Power | 3 kW | 3 kW |
| Max Lifting Height | 2030 mm | 2030 mm |
| Min Height | 100 mm | 100 mm |
| Overall Width | 3560 mm | 3560 mm |
| Net / Gross Weight | 714 kg / 749 kg | 784 kg / 819 kg |
| Package Size (Main) | 2866 × 842 × 510 mm | 2870 × 842 × 510 mm |
| Package Size (Accessory) | 820 × 350 × 637 mm | 820 × 350 × 637 mm |
