Custom Wholesale Price| Gantry Type Two Post Lift
Product Highlights:
- The hydraulic circuit is equipped with explosion-proof valves to ensure safe operation. The sliders are made of nano-material, featuring self-lubrication and wear resistance, and require no maintenance for life. Two different installation angles are available for convenient vehicle door opening.
- The whole machine adopts an environmentally friendly and low-noise design. It offers two types of column extension devices: 600mm column extension arms and 1200mm column extension arms, providing different space options. The columns are constructed with an 8-bend structure and built-in reinforcing ribs, maximizing column strength. The unique electronically controlled lock structure ensures zero failure.
- The base plate is 20mm thick, and the support arms are 6mm/8mm thick. The inverted-mounted hydraulic cylinder has a low failure rate. Door anti-collision rubber strips are installed on the sliders and support arms for convenient access of people and vehicles. It features an 1.8-meter extra-long slider design. The integrated rubber pad tray structure is durable and long-lasting.
- Each lift has passed 115% dynamic load test and 150% static load test, ensuring the safe and reliable operation of every piece of equipment.
- The Lifts are covered by global product liability insurance.
Technical Parameters:
| Parameter | 450-WT46E | 450-WT48E |
| Lifting Capacity | 4500kg | 4500kg |
| Auxiliary Lifting Capacity | 3000kg | 3000kg |
| Lifting Height | 2070mm | 2070mm |
| Minimum Height | 230mm | 230mm |
| Auxiliary Lifting Height | 400mm | 400mm |
| Platform Length | 4600mm | 4800mm |
| Overall Length | 6110mm | 6310mm |
| Platform Width | 680mm | 680mm |
| Platform Spacing | 900mm | 900mm |
| Motor Power | 3.5KW | 3.5KW |
| System Pressure | 250bar | 250bar |
| Net Weight / Gross Weight | 2713kg / 2880kg | 2773kg / 2940kg |
